Inch Single Row
Single-row tapered roller bearings are the most basic and widely used, consisting of a cone assembly and a cup. We offers the world's widest variety in inch and metric sizes.
Inch Double Row
​Double- or two-row tapered roller bearings feature double cups and two single cones. They are available in a variety of configurations for general industrial and automotive applications.

Applications:
Automotive rear wheels
Transmissions
Gear reduction units
Industrial equipment
Heavy-duty gear drives
Various industrial configurations

Withdrawal sleeves can be used to mount bearings with a tapered bore onto the cylindrical seat of stepped shafts. The sleeve is pressed into the bore of the bearing inner ring, which abuts a shaft shoulder or similar fixed component. The sleeve is located on the shaft by a nut or an end plate. KM or HM lock nuts (Lock nuts requiring a keyway) with appropriate locking devices are suitable. Lock nuts are not supplied with the sleeve and must be ordered separately.

The tensioning wheel is mainly composed of a fixed housing, tensioning arm, wheel body, torsion spring, rolling bearing, and spring shaft sleeve. It can automatically adjust the tension force according to the different tightness of the belt, making the transmission system stable, safe, and reliable.

Cam followers (stud-type track rollers) are designed to run on all types of tracks and to be used in cam drives, conveyor systems, etc. They are based on either needle or cylindrical roller bearings. Instead of an inner ring, they have a threaded solid stud (pin). We supplies them ready-to-mount. They are available in several designs and variants:
*With or without a cage
*With different stud designs:
A concentric seat
An eccentric collar
*With several sealing solutions
*With the outer ring running surface profile:
Crowned as standard
Cylindrical (flat)
In contrast to ball and roller bearings, where the bearing size refers to the bore diameter d, for cam followers the size refers to their outside diameter D.

Excavator specialized angular ball bearing are used for the application of excavator machiner .This kind of angular contact ball bearing has big contact angle(40 degree),so can under take big axial load ,and aslo axial radial allied load .Moreover it can carry heavier load capacity than the same size bearings because it has more balls inside .It is widely used for all imported exavator.

Backing bearings are available in many designs and variants. The main assortment is based on double or three-row cylindrical roller bearings. Single row needle roller bearing and double row tapered roller bearing designs are also available.
Backing bearings have been specially developed for cold rolling mills of the cluster type, but can also be used for other applications, such as straightening or bending machines. These bearings have a particularly thick-walled outer ring and can be mounted on stationary support shafts to form backup or straightening rolls.

Accessories extend the design flexibility of mounted bearing solutions consisting of housings with bearings. In this section, you can find details about housing seals, end covers, and locating rings. Information about other accessories, such as lubricators or sensors for condition monitoring is available under Lubrication management and Condition monitoring systems.
Housing seals
The seals are intended to fit into the seal grooves in the housing. They accommodate a variety of operating and ambient conditions.
Designs and variants
End covers
End covers are static seals, which can be inserted in the seal groove when the housing is used at the end of a shaft.

Deep groove ball bearings are suitable for high-speed or even extremely high-speed operation, and are very durable. This type of bearing has a low friction coefficient, high maximum speed, diverse size range and form variations, and is widely used in industries such as precision instruments, low-noise motors, automobiles, motorcycles, and general machinery. It is the most widely used type of bearing in the mechanical industry. It mainly bears radial loads and can also withstand a certain amount of axial loads.

Deep groove ball bearings are a type of bearing that has a wide range of applications. Open type deep groove ball bearings are one of the most commonly used types, featuring a larger contact surface area than other types. This allows for greater friction and heat transfer, making them ideal for use in high-temperature or high-pressure environments. They also have a lower coefficient of friction than other types, which can help to reduce energy consumption and increase efficiency.

Timken tapered bearings are uniquely designed to manage both thrust and radial loads on rotating shafts and in housings. We manufacture nearly 26,000 bearing combinations – in single, double and four-row configurations. Customized geometries and engineered surfaces can be applied to these bearings to further enhance performance in demanding applications.

Lock nuts are used to locate bearings onto a shaft. Additionally, they can be used to mount bearings with a tapered bore onto tapered shaft seats and adapter sleeves, and to dismount bearings from withdrawal sleeves. Lock nuts are also frequently used to secure gears, belt pulleys and other machine components.

Lock nuts have to be secured to prevent unintentional loosening by:

A locking device that engages a keyway in the shaft or *key slot in the adapter sleeve,
* Or a locking mechanism integrated in the nut.


SKF lock nuts provide a variety of ways to secure the nut onto a shaft. The lock nuts listed here constitute the basic SKF assortment. Lock nuts with other locking methods can be supplied on request. For additional information, contact SKF.

industrial lock nuts:
*Requiring a keyway
*With integral locking

precision lock nuts :
*With integral locking

Lock nuts with integral locking reduce the cost of the shaft as no keyway is required. Installation is quicker and easier because no separate locking device is necessary. However, the loosening torque of these lock nuts requires more attention. For information on loosening torque, refer to the product data sections for the various lock nut series

Lock nuts are used to locate bearings onto a shaft. Additionally, they can be used to mount bearings with a tapered bore onto tapered shaft seats and adapter sleeves, and to dismount bearings from withdrawal sleeves. Lock nuts are also frequently used to secure gears, belt pulleys and other machine components.

Lock nuts have to be secured to prevent unintentional loosening by:

A locking device that engages a keyway in the shaft or *key slot in the adapter sleeve,
* Or a locking mechanism integrated in the nut.


SKF lock nuts provide a variety of ways to secure the nut onto a shaft. The lock nuts listed here constitute the basic SKF assortment. Lock nuts with other locking methods can be supplied on request. For additional information, contact SKF.

industrial lock nuts:
*Requiring a keyway
*With integral locking

precision lock nuts :
*With integral locking

Lock nuts with integral locking reduce the cost of the shaft as no keyway is required. Installation is quicker and easier because no separate locking device is necessary. However, the loosening torque of these lock nuts requires more attention. For information on loosening torque, refer to the product data sections for the various lock nut series
